Alco "S-6" Locomotives

The Alco S6 was the sixth model of switcher series the company produced and debuted in 1955 and built until 1960. The S6, up to that time, would prove to be American Locomotive's least successful switcher design with fewer than 130 purchased and none were ultimately built by the Montreal Locomotive Works.

The model was based from Alco's custom S5 locomotive built exclusively for the Boston & Maine Railroad, which had asked for a switcher with a bit less horsepower. Similarly, the S6 offered less power than the S4 as Alco looked to capture the market for such but ultimately would not find a lot of interest.

Still, a handful of railroads and industries did purchase the S6 including several foreign lines (the Southern Pacific would wind up with 55% of the total number built).

Today, at least two S6s are known to exist; Southern Pacific #1034 (at the National Railroad Museum) and #1051 (in operation at the Niles Canyon Railway). Both units still carry their original number and livery.

Southern Pacific S6 #1085 appears to be tied down with its caboose at Newhall Yard in San Jose, California during August, 1964. Drew Jacksich photo.

The Alco S6 (designed by the company as its DL430) was quite similar to all of its previous siblings, and as aforementioned was the successor to Alco's S5 design. The S5 was the first switcher to employ Alco's very own prime mover, the model 251A, which was capable of producing 800 horsepower via 6 cylinders.

As John Kirkland notes in his book, "The Diesel Builders: Volume Two," the S5 was essentially an experimental design.  It featured a 251A, 6 cylinder in-line engine capable of producing 800 horsepower.

Interestingly, the builder decided not to use its troublesome model 244 prime mover in any of its switchers, which was unsuccessful in its main line freight locomotives like the PA and FA but had worked quite well in its early Road Switcher (RS) line (the RS1, RS2, and RS3 in particular).

In any event, whereas the S5 used Alco's 251A diesel engine the S6 used the updated 251B equipped with 900 horsepower. Also, just as with the S3 and S4, the S5 and S6 were equipped with updated AAR type A trucks and not the Blunt trucks used on the early models.

As you can see, both designs were quite similar especially the external carbody. Both units were 45 feet, 5 inches in length and weighed 115 tons. The most noticeable differences could be internally (aside from the slightly different prime movers).

The S5 offered dynamic braking and the S6 did not (it was the only model that did not offer this feature). However, the S6 featured a higher starting tractive effort, 61,500 pounds compared to the S5's 57,500 pounds. And, as was the case with almost all Alco models of any type, both used traction motors and air components from General Electric and Westinghouse.

South Buffalo Railway S-6's #43 and #44 roll into C Yard on July 29, 1984 with S-2's #103 and #106 in the distance. Note the Baltimore & Ohio unit to the far left. Doug Kroll photo.

It should also be mentioned that Alco offered a cow-calf version of the S6, the SSB-9A/SSB-9B. This design was built exclusively for Oliver Iron Mining of northern Minnesota.

The operation moved and shuffled ore jimmies for the Duluth, Missabe & Iron Range Railway that served the mines north of Duluth at locations like Ely, Mt. Iron, and Coleraine. Oliver Iron fleeted a large collection of switchers and was interested in as much horsepower and tractive effort as possible to move heavy ore.

Essentially, the SSB-9 cow-calf was setup was simply an S6 with a cabless S6 semi-permanently attached. In total, Oliver Mining purchased two sets of this locomotive; #1217A-1217B and #1218A-1218B.

One of Boston & Maine's rare S5's, #1282, is seen here dead outside the shops at North Billerica, Massachusetts on June 20, 1978. The unit began its career as #865. Doug Kroll photo.

The Alco S6 sold modestly at just 126 units although they could be found coast to coast among a handful of Class Is like the Southern Pacific (which bought 70) and Western Maryland as well as industries like ARMCO Steel, Republic Steel, and Semet-Solvay.

Additionally, Mexican lines including the Chihuahua Pacifico, Cia Fundidora de Hierro y Acero, Ferrocaril del Pacifico, National de Mexico, Secretarias Communicaciones de Obras Publicas, and Unidos de Yucatan purchased 33 S6s between them.

Alco S5 Data Sheet

Entered Production8/13/1951 (Demonstrator #6*)
Years Produced8/13/1951-6/28/1954
Model SpecificationDL421/A
Engine251A, 6-Cylinder In-Line
Horsepower800
RPM1000
Carbody StylingAlco
Length (Between Coupler Pulling Faces)45' 5.75"
Width10'
Height Above Rail Head14' 8"
Weight230,000 Lbs. or 248,000 Lbs.
TrucksB-B
Truck TypeGRS Rigid Bolster, Drop-Side Equalizer (AAR Type-A)
Truck Wheelbase8'
Wheel Size40"
Traction MotorsGE 752 (4)
Traction GeneratorGT854
Gear Ratio74:18
Tractive Effort Rating46,000 Lbs. at 5 MPH.
Top Speed60 MPH

* This locomotive was built as a test-bed model only by Alco (construction number 77991) and the only variant carrying the specification DL421 (all other S5's were built to specification DL421A).   It was never available for sale and eventually scrapped.

Alco S5 Production Roster

Owner Road Number(s) Construction Number(s) Completion Date
Alco (Demo)909 (Became Island Creek Fuel & Transportation Company #102)809156/14/1954
Boston & Maine860809166/22/1954
Boston & Maine861809176/16/1954
Boston & Maine862809186/21/1954
Boston & Maine863809196/27/1954
Boston & Maine864809206/27/1954
Boston & Maine865809216/28/1954
Island Creek Fuel & Transportation Company#102 (Ex-Demo #909)80915Acquired 8/3/1954

Alco S6 Data Sheet

Entered Production5/6/1955 (Northern Pacific #750)
Years Produced5/6/1955-12/2/1960
Model SpecificationDL430 (1st)
Engine251B, 6-Cylinder In-Line
Horsepower900
RPM1000
Carbody StylingAlco
Length (Between Coupler Pulling Faces)45' 5.75"
Width10'
Height Above Rail Head14' 6"
Weight196,000 Lbs.; 230,000 Lbs.; 248,000 Lbs.
TrucksB-B
Truck TypeGRS Rigid Bolster, Drop-Side Equalizer (AAR Type-A)
Truck Wheelbase8'
Wheel Size40"
Traction MotorsGE 752 (4)
Traction GeneratorGT854
Gear Ratio74:18
Tractive Effort Rating46,000 Lbs. at 5 MPH.
Top Speed60 MPH

Alco S6 Production Roster

Owner Road Number(s) Quantity Date Built
Armco Steel Corporation120211956
Belt Railway Of Chicago42011957
B. Perini & Sons, Inc.10111956
Columbia Geneva Steel111957
Ferrocarril Chihuahua al Pacífico (Mexico)60817151/1956
Fundidora de Fierro y Acero de Monterrey (Mexico)1-282305-8230612/1958-1/1959
Fundidora de Fierro y Acero de Monterrey (Mexico)38230812/1960
Ferrocarril del Pacífico (Mexico)701-70881302-813096/1955-8/1955
Ferrocarril del Pacífico (Mexico)709813849/1955
Ferrocarril del Pacífico (Mexico)710-72481405-814199/1955-10/1955
Ferrocarriles Nacionales de México (Mexico)5300817161/1956
Ferrocarril del Sureste (Mexico)7133-1, 7133-281814, 8181510/1956
Ferrocarril del Sureste (Mexico)7133-38181211/1960
Ferrocarriles Unidos de Yucatán (Mexico)*3018181111/1960
Northern Pacific75011955
Ohio River Company5611956
Republic Steel Corporation153, 317-31831957-1959
Semet-Solvay Company11011956
Sheffield Steel15-1621957
South Buffalo Railway40-4561955-1956
Southern Pacific1033-1090, 4634-4645701955-1956
Tennessee Copper Company10711957
U.S. Pipe & Foundry Company3811956
Western Maryland151-15221956

* The Ferrocarriles Unidos de Yucatán was a 3-foot, narrow-gauge system operating in the states of Yucatán and Campeche, Mexico from 1902-1975.

Sources:

  • Foster, Gerald. A Field Guide To Trains. New York: Houghton Mifflin, 1996.

  • Kirkland, John F. Diesel Builders, The:  Volume Two, American Locomotive Company And Montreal Locomotive Works. Glendale: Interurban Press, 1989.

  • Pinkepank, Jerry A. Diesel Spotter's Guide.  Milwaukee: Kalmbach Publishing Company, 1967.

  • Solomon, Brian. Alco Locomotives. Minneapolis: Voyageur Press, 2009.


Winchester & Western S6 #80 leads an RS3 as the two Alcos perform switching work at the small yard and shops in Gore, Virginia during the fall of 1989. The switcher began service as Southern Pacific #4644 in December of 1955. Wade Massie photo.
