GE/Wabtec "ET44AC" Locomotives

Last revised: December 3, 2022

By: Adam Burns

The ET44AC, along with the ET44C4, was General Electric's final production road-switcher before the transportation division was sold to Wabtec Freight in 2019.

This particular model was part of its Evolution Series, a stand alone variant aimed at meeting the Environmental Projection Agency's latest Tier IV emissions standards that went into affect on January 1, 2015.

GE had been successful in adapting its previous ES44AC to meet EPA's Tier III standards (January 1, 2012).  This same locomotive was revolutionary when it debuted in 2003 to meet EPA's then Tier II standards (January 1, 2005).

While the company's new GEVO prime mover was up to the challenge, GE was still forced to make changes in meeting Tier IV demands.  In addition, engineers had to redesign other aspects of the locomotive's radiator and internal components.

To date, there have been a few hundred examples of the ET44AC produced since it debuted in 2015.  As of this writing Canadian National, CSX, Norfolk Southern, and Union Pacific have all purchased the model.

In addition, BNSF has acquired more than 200 examples of the ET44C4, the A1A-A1A variant first introduced in 2009 as the ES44C4.

Photos

General Electric ET44AC demonstrator #2031 in service on the BNSF at Verdemont, California on February 16, 2016. Paul Wester photo. American-Rails.com collection.

Background

Since the ET44AC remains in production, the information here may not be current.  As such, it will be amended over time as the latest data is made available.

General Electric's 'Evolution Series' unofficially debuted in March, 2002 when testbed #2005 rolled out of Erie.  This unit, which ushered in the builder's production model ES44AC of 2005, marked a new era in locomotive development.

The company spent hundreds of millions of dollars on development of a new prime mover to meet the EPA's then Tier II environmental emissions standards.

GE's rugged FDL prime mover, an engine with origins dating back to Copper Bessemer and the first U25B's of 1959, could no longer be refined without seriously degrading performance.

As a result, the all new GEVO power plant was unveiled and entered full scale production in December, 2002.

Union Pacific ET44AC #2734 leads a general manifest through Colton, California on October 14, 2016. Paul Wester photo. American-Rails.com collection.

GE engineers were also forward-thinking in the GEVO's design, enabling it to meet future standards beyond Tier II.  This proved important when Tier III standards went into effect in 2012 as the company only needed to implement minor internal improvements to its 'ES' models.

However, meeting more stringent Tier IV standards proved a problem.  In his book, "Locomotives, The Modern Diesel & Electric Reference: 2nd Edition," Greg McDonnell notes the carbody had to incorporate several design changes.

For sharp-eyed railfans, the most noticeable difference between the ES44AC and ET44AC includes:

  • A larger rear flared radiator with a pronounced "V" appearance.

  • Inclusion of the horns just above the cab as well inset within the radiator at the rear.  These had previously been located at the center of the carbody in one grouping, but GE needed this space for additional components.

  • The overall height of the cab was increased to 16 feet, 1 inch.  As such, the ET44AC has reached its maximum possible height and still meet clearance restrictions, such as tunnels and overpasses.

With Wabtec Freight acquiring General Electric's transportation division in early 2019, the future of not only the locomotive production market but also that of GE-designed products is interesting.

GE had nearly limitless resources in developing technologically advanced models that had far surpassed EMD by the 1990s, such as the AC4400CW and C44-9W.

This continued with the Evolution Series in the early 2000s.  It will be fascinating to see how Wabtec Freight navigates the locomotive market moving forward.

Data Sheet

ET44AC

Entered Production8/24/2012 (General Electric #2015)
Years Produced8/24/2012 - Present
GE ClassES44TC
EngineGEVO-12 Tier IV (12 cylinder)
Engine BuilderGeneral Electric
Horsepower4400
RPM1050
Length74' 6"
Height (Top Of Rail To Top Of Cab)16' 1"
Width9' 11"
Weight426,000 - 432,000 Lbs
Fuel Capacity5,000 Gallons
Air Compressor3CDC (Westinghouse)
Air Brake Schedule26L (Westinghouse)
TrucksC-C
Truck TypeHi-Ad Bolsterless Or Steerable (GE)
Truck Wheelbase13' 2"
Wheel Size42"
Traction MotorsGEB13 (6), GE
Traction AlternatorGMG205, GE
Auxiliary AlternatorGYA30A, GE
MU (Multiple-Unit)Yes
Dynamic BrakesYes
Gear Ratio83:20
Tractive Effort/Starting183,000 Lbs
Tractive Effort/Continuous166,000 Lbs at 13.7 mph
Top Speed70 mph

ET44C4

Entered Production4/2015 (BNSF #3911)
Years Produced2015 - Present
GE ClassES44C4
EngineGEVO-12 Tier IV (12 cylinder)
Engine BuilderGeneral Electric
Horsepower4400
RPM1050
Length74' 6"
Height (Top Of Rail To Top Of Cab)16' 1"
Width9' 11"
Weight416,000 Lbs
Fuel Capacity5,000 Gallons
Air Compressor3CDC (Westinghouse)
Air Brake Schedule26L (Westinghouse)
TrucksA1A-A1A
Truck TypeHi-Ad Bolsterless (GE)
Truck Wheelbase13' 2"
Wheel Size42"
Traction MotorsGEB13 (4), GE
Traction AlternatorGMG205, GE
Auxiliary AlternatorGYA30A, GE
MU (Multiple-Unit)Yes
Dynamic BrakesYes
Gear Ratio83:20
Tractive Effort/Starting183,000 Lbs
Tractive Effort/Continuous166,000 Lbs at 13.7 mph
Top Speed70 mph

Production Roster

ET44AC

Owner Road Number Serial Number Order Number Completion Date Quantity
Canadian National3121625211810 (Ex-Demonstrator #2029)20141
Canadian National3122-313262525-625351834 (Ex-Demonstrators #2033-2043)201411
Canadian National3000-303863438-6347718417/2015-9/201539
Union Pacific2570-266963478-63577184710/2015-12/2015100
CSX Transportation3250-329963578-63627184510/2015-12/201550
CSX Transportation3300-337463628-63702184510/2015-12/201575
CSX Transportation3375-347463703-6380218501/2016-12/2016100
Canadian National3039-312063858-6394518521/2016-8/201682
Norfolk Southern3600-364664093-6413918565/2016-6/201647
Union Pacific2670-276464303-6439718577/2016-10/201695
Norfolk Southern3647-368064535-64568-1/2017-4/201734
Canadian National3133-316264774-64803-10/2018-11/201830
Canadian National3163-317265858-65867-11/2018-12/201810
Canadian National3173-322265868-65917-1/2019-4/201950
Canadian National3223-323266088-66097-1/2019-5/201910
Canadian National3233-324266098-66107-1/2019-5/201910
Canadian National3243-328566252-66294-12/2019-2/202043

Some lines, like CSX, denote their ET44AC as the "ET44AH," with the "H" referring to "Heavy" regarding its additional ballast.

ET44C4

Owner Road Number Serial Number Order Number Completion Date Quantity
BNSF Railway3911-391563164-6316818434/20155
BNSF Railway3916-399963169-6325218434/2015-9/201584
BNSF Railway3839-391063253-6332418439/2015-11/201572
BNSF Railway3764-383864015-6408918492/2016-6/201675
BNSF Railway3725-376364569-64607-3/2017-6/201739
BNSF Railway3675-372466139-66188-11/2019-6/202050

Sources

  • McDonnell, Greg. Locomotives: The Modern Diesel & Electric Reference, 2nd Edition. Buffalo: Boston Mills Press/Firefly Books, 2015.
  • Solomon, Brian.  GE and EMD Locomotives:  The Illustrated History.  Minneapolis:  Voyageur Press, 2014.
  • McDonnell, Greg. U-boats.  Toronto: Stoddart Publishing, 1994.

Canadian National ET44AC #3029 at the Woodcrest Shops (ex-Illinois Central) in Homewood, Illinois; September 30, 2018. Joe Ferguson photo. American-Rails.com collection.

A1A-A1A Design

The ET44C4 was introduced alongside the ET44AC and to date, only BNSF has acquired the model.  It was a return of the A1A-A1A wheel arrangement whereby the center axle is unpowered.

General Electric had first reintroduced the concept in the earlier ES44C4.  BNSF was also the only buyer but wound up with some 1,137 examples.

What the company dubbed its Dynamic Weight Management System, Mr. McDonnell's book notes that "the computer redistributes the load from the unpowered center axles onto the powered 1, 3, 4, and 6 axles as demand warrants."
