General Motors Diesel, Ltd. (GMD)

Interestingly, the leading American locomotive manufacturer of the times was the last to establish a plant in Canada.  General Motors Diesel, Ltd. (GMD) was the Canadian arm of General Motors' Electro-Motive Division, which was established during the late 1940s to offer EMD products in that country and bypass the steep tariffs and customs rates required to ship locomotives across the border.  GMD's plant was located in London, Ontario and began full production by the early 1950s.  The division (later renamed as the General Motors Diesel Division or GMDD) would manufacture most of EMD's catalog for Canadian railroads and ironically outlived its counterpart facility in La Grange, Illinois which closed during the early 1990s.

The London plant continued to build locomotives until early 2012 when new owner Caterpillar shutdown the facility and moved all operations back into the United States.  The uproar over the move was significant with the general public and media strongly condemning the decision.  However, the company, long known for its line of construction equipment, was unswayed by the firestorm.  Today, remaining EMD production can be found in Muncie, Indiana.

A set of new Canadian Pacific SD40-2F's are seen here in London, Ontario on March 12, 1989. Brian Rackley photo.

In 1949 General Motors established General Motors Diesel, Ltd. to serve the Canadian railroad industry and offer its successful line of diesels in that country, which were already very popular in the United States.  However, surprisingly, GMD was late to enter this market.  During 1948 Baldwin began working with the Canadian Locomotive Company (CLC) of Kingston, Ontario to sell its designs in that country although this partnership was short-lived (in 1950 CLC began working with newcomer Fairbanks Morse when it realized Baldwin would not remain competitive in the market).  The American Locomotive Company (Alco) on the other hand had long been established in Canada since 1901 through its Montreal Locomotive Works and had been manufacturing diesels since 1941.

One of the most interesting designs to come out of General Motors Diesel was the GMD-1 light road-switcher. Here, Canadian National #1002 lays over at Thorton Yard in Point Mann, British Columbia on September 20, 1987. The design was purchased primarily by CN for use on light branch lines. It featured A1A-A1A trucks and could produce 1,200 horsepower. Roger Puta photo.

There were primarily two factors driving locomotive builders to establish subsidiaries in Canada; first, EMD had overwhelmingly demonstrated the success of diesel application in road service with its FT model of 1939 and second, the country had strict laws against imported locomotives to protect its own companies.  To get around this American manufacturers found it easier to simply build their own plants in Canada instead of paying out the steep custom and tariff rates.  Before Electro-Motive's new facility in London began producing locomotives the builder had already been demonstrating its covered wagons in the country since the late 1940s including such models as the F3, E7, FP7, and others.  Not surprisingly, just like with American railroads Canadian lines were impressed with the locomotives.

The London plant built many F units but one design unique to Canada was the FP9. Here, Canadian National #6501 arrives in Dorval, Quebec with train #14, the "International Limited," on September 6, 1965. Roger Puta photo.

By the summer of 1950 General Motors Diesel was producing locomotives with the first completed being Toronto, Hamilton & Buffalo GP7 #71 that August.  A month later GMD finished what was actually the first order received by the plant, Canadian Pacific FP7s #4028-4037, which were delivered in September.  Considering Electro-Motive's success in the American market it's not considerably shocking that GMD also did quite well producing most of its parents designs including the F7, FP7, FP9, F9, GP7, GP9, GP30, SW8, SW900, SW9, SW1200, MP15AC, GP38/-2/W, GP40/-2/TC,  SD40/-2, SD38-2, and others.  It also built locomotives only used in Canada such as the GMD-1 (a light road-switcher that resembled Alco's RS-1) and cowl designs of popular Geeps and Special Duty (SD) models that were uncommon in the U.S.

Electro-Motive first introduced wide cabs in the 1970's for Canadian National, known as the Comfort Cab, Wide Cab, or Safety Cab. The first unit to receive it was GP38-2W #5560 in 1973. Here, GP40-2LW #9550 and a mate lead a freight westbound near Lake Ontario at Lovekin, Ontario in March, 1980. Roger Puta photo.

During the 1960s the London plant also began producing other equipment such as transit buses, suburban coaches, and heavy earthmoving equipment.  On February 1, 1969 GM began restructuring Canadian operations and renamed GMD as the Diesel Division of General Motors of Canada, or General Motors Diesel Division (GMDD) for short.  As time passed GM began shifting more production to London, particularly as General Electric became a serious competitor during the 1970s.  Within a decade GE had claimed top spot as locomotive manufacturer when EMD stumbled with its SD50 model in 1981 (which was supposed to be the builder's next generation of road-switcher).

A pair of Ontario Northland FP7's, built by GMD in the early 1950's, are stopped with their train at Cochrane, Ontario in November, 1978. Roger Puta photo.

General Motors Diesel Models

F Series

Model Type Units Built Date Built Horsepower
F7A831951-19531,500
F7B471951-19531,500
FP7531950-19531,500
FP9A541954-19581,750
FP9B461954-19581,750
F40PH619783,000
F40PH-2591987-19893,000
F59PH4219783,000

GP Series

Model Type Units Built Date Built Horsepower
GP7891950-19581,500
GP96461954-19631,750
GP30219632,250
GP35251964-19662,500
GP38211970-19712,000
GP38-22061973-19862,000
GP38-2W511973-19742,000
GP40161966-19673,000
GP40TC819663,000
GP40-2W461973-19763,000
GP40-2LW2331974-19753,000

SD Series

Model Type Units Built Date Built Horsepower
SD403301966-19713,000
SD40-25241972-19853,000
SD40-2W1211975-19803,000
SD40-2F2519883,000
SD38-2419752,000
SD50F601985-19873,500
SD60F641985-19893,800

Switchers

Model Type Units Built Date Built Horsepower
SW8651950-1954800
SW900881954-19691,200
SW9291950-19531,200
SW12002971955-19641,200
MP15AC419841,500

Other Designs

Model Type Units Built Date Built Horsepower
GMD11011958-19601,200
NF11091952-19531,500
NF210381956-19601,200


A pair of CP Rail (Canadian Pacific) SD40-2's are eastbound with a short train at Newtonville, Ontario in September, 1982. These locomotives were built in London during the mid/latter 1970's. Roger Puta photo.

In 1991 as EMD continued to lose market share to GE it shuttered its famous La Grange, Illinois plant and shifted all production to London under the North American Free Trade Agreement (NAFTA), which essentially abolished the General Motors Diesel Division name.  Ironically, things would come full circle within 20 years.  In 2005 GM exited the locomotive market, selling its EMD subsidiary to investment groups, which renamed it as Electro-Motive Diesel, Inc.  Five years later on August 2, 2010 Progress Rail Services Corporation, a Caterpillar subsidiary, took controlling interest in EMD.  During early 2012 a long-time contract dispute with CAW workers at the former GMD facility resulted in Caterpillar closing the plant and moving all operations to Muncie, Indiana thus ending continuous production in London after 60 years of operation.
